| Place of Origin: | China |
| Brand Name: | OEM |
| Certification: | CE , ISO |
| Minimum Order Quantity: | 1 unit |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Standard Export Packing |
| Delivery Time: | 15-20 days |
| Payment Terms: | L/C, T/T, Western Union, Paypal |
| Supply Ability: | 100pcs per month |
| Plate Type: | Screen Printer | Condition: | New |
|---|---|---|---|
| Usage: | PCB Printer | Automatic Grade: | Automatic |
| Color & Page: | Multicolor | Voltage: | 220V 50/60Hz |
| Gross Power: | 500W | Dimensions(L*W*H): | 1200X1100X1550 Mm (L X W X H) |
| Weight: | 500KG | Warranty: | One Year |
| Application: | PCB Of LED ,0402 And Above | Working Type: | Automatic Online |
| PCB Printing Size: | 400 X 300mm | Stencil Size: | 600 X 550mm |
| PCB Thickness: | 0.4 To 5mm | Conveying Height: | 900±40mm |
| Transfer Direction: | Left To Right Or Right To Left | Transportation Speed: | 0 To 100mm/sec, Adjustable |
| Printing Mode: | Single Or Doule Squeegee | Name: | LED Printed Circuit Board Solder Paste SMT Stencil Printer Machine |
| High Light: | 500KG SMT Stencil Printer,500W Solder Paste Stencil Printer,500W SMT Stencil Printer |
||
Feature:
1. Control system, adopt touch screen + PLC control, automatic operation, avoid big plate bending
2. Stable communication with other machines , to improve productivity
3. Transportation speed is adjustable , high stability
4. Suspension scraper design, squeegee pressure automatically balanced.
5. Accurate floating printing table with X,Y,Z, Micro-adjustable system.
6. automatically indicates the error and offers guidance.
7. High precision motor: adopts linear square track accompanied with inverter transmission.
8. Name: Automatic Online LED Printed Circuit Board Solder Paste SMT Stencil Printer Machine
Specification:
| PCB Printing Size |
400 X 300 mm (L X W) |
|
Stencil Size |
600 X 550 mm |
|
Thickness of PCB |
0.4 to 5.0 mm |
|
Conveying Height |
900 ± 40 mm |
| Transfer Direction |
Left to Right or Right to Left |
| Transfer Speed |
0 to 100 mm / sec , adjustable |
|
Transfer Weight |
5KG |
| Communication |
SMEMA |
|
PCB Positioning Method |
Edge and hole |
|
Printing Precision |
± 0.1 mm |
|
Repeat Precision |
± 0.05 mm |
|
Dimension |
1200x1100x1550mm(L`W`H) |
|
Net Weight |
500Kg |
